The overall process and the processing of 2”, 3”and 4”wafer sizes are provided for small-scale production of key devices and innovative devices. We accept requests for trial processing, prototyping, and small-scale fabrication and also for single process steps such as etching and insulating membrane formation, etc.

Process flow diagram

Basic_Process_Services01

We have no in-house vacuum process available for special prototyping.

There is no engineer who is able to manage overall process control.

We want to prototype newly designed devices, but don't want to fabricate in-house in order to avoid contamination of the production line.


If you have any of the above requirements, please feel free to contact NTT-AT.

Basic process services Inquiry

Specifications

Thin film

We provide a thin film fabrication service and a simple photolithographic patterning service using the equipment below.
We will also undertake partial processing and mask design. The following are only typical examples.
We can handle other materials. Please contact us.

Basic_Process_Services02 Basic_Process_Services03
6-inch metal laminated film
Thin-film inductor
(4×5.5mm and 0.5-mm thickness per element)









Benefits/Features

Features

Materials that can be deposited Single metal film
Ag, Al, Au, Bi, Co, Cr, Cu, Fe, Mg, Mn, Mo, Nb, Ni, Pb, Pd, Pt, Re, Rh, Ru, Sn, Sc, Ta, Ti, V, W, Zr We can fabricate films of other materials if you provide them.

Alloy film
AnSn, CoNi, CoP, 45Ni-Fe, 81Ni-Fe, CoZrTa, CoCr, etc

Oxide film
Al2O3, B2O3, ITO, MgO, SiO2, thermal oxide Si, Ta2O5, TiO2, etc.

Other
B, B4C, BN, C, CaF2, Ge, SrF2, MgF2, Cr3C2, LiF, SrF2, SiC, SiN, TiN, various silicides, etc.

Substrates
Usually, up to 4-inch (101.6-mm) in diameter is supported. Up to 8-inch in diameter is supported by magnetron sputtering systems. With some materials, only up to 2-inch in diameter is supported.

Film quality
We can attach the results of chemical composition analysis and impurities analysis using AES, SIMS and fluorescent X-ray analysis. Also, we will monitor the pattern configuration using an SEM.

Patterning
We provide simple patterning including mask design.
The main etching method is ion beam etching. Pattern precision is 3 mm.

Specifications/Details

Applications

  1. Film for various tests, including etching test
  2. Magnetic film
  3. Multi-layered X-ray mirror
  4. Analytical standard test sample

Examples

  1. Fabrication of 5-mm SiO2 on a plastic substrate while making the surface flat
  2. Fabrication of a test sample for measuring the dielectric constant of photo-resist film or SiO2 film
    (Patterning of 1-mm or 2-mm-diameter dielectric film which is sandwiched between Cu films)
  3. Fabrication of 15-mm SiO2 on ceramic substrate
  4. Fabrication of permalloy film on glass substrate and measurement of its BH characteristics
  5. Fabrication of Cu electrode film in mid-process
  6. Patterning of ITO electrode terminal on glass substrate
  7. Fabrication of thin-film inductor
  8. Fabrication of laminated

Basic process services Inquiry

Au nano patterns

Benefits / Features

Fabrication of Au nano patterns for biotechnology and biochemical technology

  • Available substrate : Si or Quartz
  • Fabricate patterns smaller than 100nm
  • Dice out the substrate according to your requirement

Specifications / Details

Pattern examples

Basic_Process_Services04 Basic_Process_Services05
90nm L&S pattern 100nm dot pattern
Basic_Process_Services06 Basic_Process_Services07
Interdigitated array Electrode Planarized Electrode
(Au electrode width : 200nm)

Basic process services Inquiry

Polishing, Cleaving, Dicing, Bonding

Benefits / Features

Various post-processing services available, such as wafer polishing, cleaving, dicing, Au wire bonding, etc.

Specifications / Details

Wafer polishing

  • Wafer surface polishing, wafer backside polishing, thinning, etc.
  • Depending on different needs, various polishing machines, polishing materials availabl
Available wafers Available sizes
GaAs, InP 2, 3 inch phi, non-standard size wafer
Dicing

InP, GaAs, Si, Quartz and Sapphire substrate using high precision diamond blade and high precision process machine.

Available wafers Available sizes OPTIONS
GaAs, InP, Si, LiNbO3, quartz, sapphire, LT, SiC 2, 3, 6 inch phi, non-standard size wafer Chipping with cleaving, Chip removal, Removal of cover resist for dicing, Chip cleaning
Basic_Process_Services08
Dicing example (Si substrate)










After the dicing
We also provide "removal of protective film for dicing (such as resist)" and "cleaning" as well.

Cleaving
InP wafer, GaAs wafer using diamond pencil, scribing tool and braking tool for auto-cleaving.

Mount / Wire bonding
Mounting of electrical devices and optical device chip and Au wire bonding available

Basic_Process_Services09 Basic_Process_Services10
ex1) Au wiring with wedge bonder ex2) Au wiring with ball bonder
Notes : This content may be subject to change without notice.
           These stated pattern features and structures are representative and not guaranteed.
           Actual pattern features and structures are determined by the conditions and make-up of the samples and the required
           pattern structures, etc.

Basic process services Inquiry

Metal deposition

Benefits / Features

  • Various metal deposition processes available using resistance heating, EB deposition, sputtering, etc.
  • Metal patterning using the 2 layer resist (lift-off) is also available.

Specifications / Details

Specifications

Equipment Available metals Available wafers Available sizes
Resistance heating Au, Cr, Au-based alloys GaAs, InP, Si, Quartz, SiC, GaN 2inch phi, non-standard size wafer (< 2inch phi)
Electron beam evaporation Ti, Pt, Au, Cr, AuGe, Al, Ni 2, 3, 4, 6inch phi, non-standard size wafer
Sputtering Au 2, 3inch phi

Advantages

  • EB evaporation achieves high purity film deposition compared to resistance heating.
  • Other metal material available with EB evaporation.Please contact us for the details
  • Able to provide metal etching for semiconductor devices
  • Patterning with Au plating is available

Examples (SEM images)

The following patterns are fabricated on some substrates using two-layer resist method with reduced projection exposure and metal laminate deposition with EB evaporation.

Basic_Process_Services11 Basic_Process_Services12
metal dot metal mesh
Basic_Process_Services13 Basic_Process_Services14
ultra fine metal (Ti/Au)
(width:400nmn)
nano dot(Au=50nmφ)
Basic_Process_Services15

Basic process services Inquiry

Insulating film deposition

Various types of insulating film with plasma CVD, sputtering and EB evaporation

Benefits / Features

Features

  • SiO2 layer and SiNx layer can be deposited at the temperature of 200°C and 300°C with plasma CVD
  • AR layer with highly controlled depostion technique and multi-layered HR layer with sputtering are also available(Depending on required wavelength, low reflecting film is also available.)

Specifications / Details

Specifications

Equipment / method Available insulating films Available wafers Available sizes
Plasma CVD SiNx, SiO2 GaAs, InP, Si, Quartz, Sapphire, GaN, SiC 2 - 4 inch phi, non-standard size wafer
Sputtering SiO2, TiO2, Al2O3, a-Si
Electron beam evaporation SiO2, TiO2, Al2O3
Example :

Desymmetrization of the resonator end face for semiconductor lasers
«Reflectivity of AR layer and HR layer of InP monitor substrate»

Basic_Process_Services16 Basic_Process_Services17
Reflectivity of AR Reflectivity of HR
Notes : This content may be subject to change without notice.
           These stated pattern features and structures are representative and not guaranteed.
           Actual pattern features and structures are determined by the conditions and make-up of the samples and the required
           pattern structures, etc.
