SiC membrane-based FZP, only from NTT-AT in the world

Benefits

NTT-AT's Fresnel Zone Plate (FZP), constructed from SiC membrane and Ta absorber pattern, has an outstandingly high X-ray irradiation durability, high resolution, and high contrast.

Only NTT-AT provides the SiC membrane-based Fresnel Zone Plate (FZP), which has an outstandingly high X-ray irradiation durability. NTT-AT's FZP is constructed from dry etched Ta. It has a sharp absorber pattern and achieves a high S/N ratio and low defect imaging, and is ideal for applications such as X-ray microscopes, X-ray micro-beam irradiation, and X-ray imaging.

In addition, the Ta pattern/SiN membrane-type FZP and Au plated pattern/SiN membrane-type FZP are provided for using in soft X-ray and extreme ultraviolet (EUV/XUV) regions. In addition, a Step (Kinoform) FZP is available.

Features

Key points

  • Useful for various X-ray applications such as X-ray microscopes, EUV microscopes, X-ray microbeam irradiation, and synchrotron radiation beam monitors, etc.
  • Outstandingly high X-ray irradiation durability
  • Minimum zone width up to 25 nm
  • Customized FZP also available

Standard product list with specifications

Model Aspect
Ratio
Membrane
Material
Membrane
Thickness
(µm)
ΔRn
(nm)
D (um) N Tm (nm)
FZP-S38/84 4.2 SiN 0.15 38 84 550 160
FZP-S50/80 5 SiN 0.2 50 80 400 250
FZP-S40/155 5 SiN 2 40 155 970 200
FZP-S50/330 8 SiN 1 50 330 1,650 400
FZP-S86/416 8 SiN 2 86 416 1,200 700
FZP-100/155 8 SiN 2 100 155 388 800
FZP-173/208 5.8 SiN 2 173 208 300 1,000
FZP-200/206 8 SiN 2 200 206 255 1,600
FZP-C234/2500 0.6 SiC 0.2 234 2,500 2,670 150
* Please note that the specifications may be subject to change without notice.

Rn : Outermost Zone Width
D : Diameter
N : Total Zone
Tm : Ta Thickness

Standard lead time: 12 weeks

X-ray absorber pattern of Fresnel Zone Plate (FZP)

Custom designed FZPs are available upon request to suit your specific X-ray energy, optical setup and focus/image performance. Please feel free to contact us if you cannot find a product that meets your requirements in our catalogue of standard products.
xray_fzp_001 Pattern image (φ2.5mm)
(Optical microscope)
xray_fzp_002 Observed SEM image with diagonal angle
(SEM)

Fresnel Zone Plate (FZP) Structure

xray_fzp_003 Binary type
xray_fzp_004 Step (kinoform) type
Minimum zone width (outer most zone) 25nm
Maximum diameter 5mm
Membrane material SiN, SiC
Membrane thickness 0.2-2µm
Absorber material Ta
Absorber thickness 0.1-2µm
Si substrate shape 10mm square
Si substrate thickness 1mm
*We will be pleased to discuss different requirements with you.

X-ray Fresnel Zone Plate (FZP) Inquiry

Production example

Ultra fine pattern Fresnel Zone Plate (FZP)

Fresnel Zone Plate (FZP) diameter : 250µm, Ta thickness : 125nm, Outermost zone width : 25nm, Membrane : SiC 2.0µm
xray_fzp_005
xray_fzp_006

High aspect ratio (thicker Ta absorber) Fresnel Zone Plate(FZP)

Fresnel Zone Plate (FZP) diameter : 100µm, Ta thickness : 2.5µm, Outermost zone width : 250nm, Membrane : SiN 2.0µm
xray_fzp_007
xray_fzp_007

Step (Kinoform) type Fresnel Zone Plate (FZP)

Fresnel Zone Plate (FZP) diameter : 100µm, Ta thickness : 4.0µm, Outermost zone width : 400nm, Membrane : SiC 2.0µm
xray_fzp_009
SEM image of the Fresnel Zone Plate (FZP) center area :Step (Kinoform) type Fresnel Zone Plate (FZP), Ta pattern

X-ray Fresnel Zone Plate (FZP) Inquiry

Past record

The  FZP with a combination of high durability, SiC membrane and sharp-shaped Ta X-ray absorber results in a tough and highly accurately shaped product.
NTT-AT's FZP has been used in many products throughout the world, proving of its high quality.

Paper lists

Nobuhito Nango, Shogo Kubota, Akihisa Takeuchi, Yoshio Suzuki, Wataru Yashiro, Atsushi Momose, and Koichi Matsuo, “Talbot-defocus multiscan tomography using the synchrotron X-ray microscope to study the lacuno-canalicular network in mouse bone,” Biomed. Opt. Express 4, 917 (2013); http://dx.doi.org/10.1364/BOE.4.000917
K. Nogita, H. Yasuda, M. Yoshiya, S.D. McDonald, K. Uesugi, A. Takeuchi, and Y. Suzuki, “The role of trace element segregation in the eutectic modification of hypoeutectic Al–Si alloys,” J. Alloy Compd. 489, 415 (2010); http://dx.doi.org/10.1016/j.jallcom.2009.09.138
Yasushi Kagoshima, Hidekazu Takano, Takahisa Koyama, Yoshiyuki Tsusaka and Akihiko Saikubo, “Tandem-Phase Zone-Plate Optics for High-Energy X-ray Focusing,” Jpn. J. Appl. Phys. 50 022503 (2012); http://dx.doi.org/10.1143/JJAP.50.022503
extreme-ultraviolet scatterometry microscope
Tetsuo Harada, Yusuke Tanaka, Takeo Watanabe, Hiroo Kinoshita, Youichi Usui and Tsuyoshi Amano, “Phase defect characterization on an extreme-ultraviolet blank mask using microcoherent,” J. Vac. Sci. Technol. B 31, 06F605 (2013);http://dx.doi.org/10.1116/1.4826249
Nobuhiro Yasuda, Yoshimitsu Fukuyama, Shigeru Kimura, Kiminori Ito, Yoshihito Tanaka, Hitoshi Osawa, Toshiyuki Matsunaga, Rie Kojima, Kazuya Hisada, Akio Tsuchino, Masahiro Birukawa, Noboru Yamada, Koji Sekiguchi, Kazuhiko Fujiie, Osamu Kawakubo and Masaki Takata, “System of laser pump and synchrotron radiation probe microdiffraction to investigate optical recording process,” Rev. Sci. Instrum. 84, 063902 (2013); http://dx.doi.org/10.1063/1.4807858
Yoshio Suzuki and Akihisa Takeuchi, “X-ray holographic microscopy with Fresnel zone plate objective lens and double-diamond-prism interferometer,” Jpn. J. Appl. Phys. 53 122501 (2014); http://dx.doi.org/10.7567/JJAP.53.122501
Masanori Tomitaa , Munetoshi Maeda, Katsumi Kobayashi and Hideki Matsumoto, “Dose Response of Soft X-Ray-Induced Bystander Cell Killing Affected by p53 Status,” Radiation Res. 179, 200 (2013); http://dx.doi.org/10.1667/RR3010.1
W. Yashiro, Y. Takeda, A. Takeuchi, Y. Suzuki, and A. Momose, “Hard-X-Ray Phase-Difference Microscopy Using a Fresnel Zone Plate and a Transmission Grating,” Phys. Rev. Lett. 103, 180801 (2009); http://dx.doi.org/10.1103/PhysRevLett.103.180801
Yutaka Yoshida , Kazuo Hayakawa, Kenichi Yukihira, Masahiro Ichino, Yuki Akiyama, Hiroto Kumabe, Hiroyoshi Soejima, “Development and applications of “Mössbauer cameras”,” Hyperfine Interact. 198, 23 (2010); http://dx.doi.org/10.1007/s10751-010-0228-x
Akihisa Takeuchi, Yasuko Terada, Kentaro Uesugi, Yoshio Suzuki, “Three-dimensional X-ray fluorescence imaging with confocal full-field X-ray microscope,” Nucl. Instrum. Meth. Phys. Res. A 616, 261 (2010); http://dx.doi.org/10.1016/j.nima.2009.10.054
K. Horiba, Y. Nakamura, N. Nagamura, S. Toyoda, H. Kumigashira, M. Oshima, K. Amemiya, Y. Senba and H. Ohashi, “Scanning photoelectron microscope for nanoscale three-dimensional spatial-resolved electron spectroscopy for chemical analysis,” Rev. Sci. Instrum. 82, 113701 (2011); http://dx.doi.org/10.1063/1.3657156
Tatsuya Kikuzuki, Yuya Shinohara, Yoshinobu Nozue, Kazuki Ito, Yoshiyuki Amemiya, “Determination of lamellar twisting manner in a banded spherulite with scanning microbeam X-ray scattering,” Polymer 51, 1632 (2010); http://dx.doi.org/10.1016/j.polymer.2010.01.057
Sho Kanzaki, Yasunari Takada, Shumpei Niida, Yoshihiro Takeda, Nobuyuki Udagawa, Kaoru Ogawa, Nobuhito Nango, Atsushi Momose, Koichi Matsuocorrespondenceemail, “Impaired Vibration of Auditory Ossicles in Osteopetrotic Mice,” Am. J. Pathol. 178, 1270 (2011); http://dx.doi.org/10.1016/j.ajpath.2010.11.063
Akihisa Takeuchi, Kentaro Uesugi and Yoshio Suzuki, “Three-dimensional phase-contrast X-ray microtomography with scanning–imaging X-ray microscope optics,” J. Synchrotron Rad. 20, 793 (2013); http://dx.doi.org/10.1107/S0909049513018876
Akihisa Takeuchi, Yoshio Suzuki and Kentaro Uesugi, “Differential phase contrast X-ray microimaging with scanning-imaging x-ray microscope optics,” Rev. Sci. Instrum. 83, 083701 (2012); http://dx.doi.org/10.1063/1.4739761

Publication list (including co-authored papers):

Akihisa Takeuchi, Yoshio Suzuki, Kentaro Uesugi, Ikuo Okada and Hiroki Iriguchi, “Performance Test and Evaluation of Multilevel Fresnel Zone Plate with Three-Step Profile Fabricated with Electron-Beam Lithography,” Jpn. J. Appl. Phys. 51 022502 (2012); http://dx.doi.org/10.1143/JJAP.51.022502

Comparison with other companies' products

Only NTT-AT provide SiC membrane-based FZPs. Custom design is also provided. Please feel free to contact us.

Product Inquiry
